Capture/compare unit for PWM signal generation (CCU6).16-bit timers - GPT12, Timer2, Timer21, and Timer3.2 differential Sigma Delta 14-bit ADC (ADC3/4).5 analog inputs, 10-bit A/D Converter (ADC1).On-chip OSC and PLL for clock generation.It is a highly integrated AEC-Q100 Grade 0 automotive qualified device enabling cost and space efficient solutions for BLDC motor drive applications such as wipers. It includes an on-chip linear voltage regulator to supply external loads. A LIN transceiver is also integrated to enable communication to the device along with a number of general purpose I/Os. Its peripheral set includes a current sensor, a successive approximation ADC synchronized with the capture and compare unit for PWM control and 16-bit timers.
It includes six fully integrated NFET drivers optimized to drive a 3-Phase motor via six external power NFETs, a charge pump enabling low voltage operation and programmable current along with current slope control for optimized EMC behavior. The TLE9872-2QXA40 is a single chip 3-Phase motor driver that integrates the industry standard Arm® Cortex®-M3 core, enabling the implementation of advanced motor control algorithms such as field-oriented control. The TLE9872-2QXA40 is part of the MOTIX™ TLE987x product family.
